SENSING Thor Kit TRD1 G2A Developer Kit

share
WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
Model TRD1 G2A
Support Platorm NVIDIA Jetson AGX Thor
Output data RAW/YUV422
Dimensions 243.12mm*112.4mm*56.88mm
Supported Camera Resolutions Max 3840*2160
Compatible Camera Types GMSL/GMSL2
Max Supported Cameras 8*GMSL
SOC NVIDlA Jetson T5000 Module
Al Perfommance 2070 TFLOPS
Buy Now
DetailAccessoriesResources

undefined    TRD1 G2A SENSING TRD1 Series Developer Kit

TRD1 G2A Developer kit is Based on NVIDIA's official Jetson AGX Thor developer kit by adding GMSL interfaces, enabling customers to rapidly integrate image data from GMSL cameras into the Thor platform. It supports up to 8 GMSL cameras.



List of Accessories

Number

Product model

Quantity

Remark

1

TRD1 G2A

1

Up to 8 cameras at most

2

T4JC-JC-ZZZZ-0500L(Female to Female 0.5m)

2

Standard configuration

3

Trigger Cable

1

Standard configuration

4

Power Conversion Cable

1

Standard configuration

5

Power adapter1Standard configuration

6

Multi-functional conversion socket1

optional configuration




undefined    Application





　

undefined   TRD1 G2A supported camera combinations & platform

  • You may choose the following camera combinations to connect to the TRD1 G2A.

Camera Combination

Number of Supported Cameras

Remark

Comb. 1

4*8MP/30FPS

/

Comb. 2

8*3MP/30FPS/

Comb. 3

6*5MP/30FPS/

Comb. 4

2*8MP/30FPS+4*3MP/30FPS/

Comb. 5

3*5MP/30FPS+4*3MP/30FPS/

Comb. 6

2*8MP/30FPS+3*5MP/30FPS/



  • The GMSL camera can be connected to TRD1 G2A ,Please obtain the SDK driver through the Github Link.



For more details, please refer to the product specifications or contact sales personnel at email sales@sensing-world.com





List of Accessories

Number

Product model

Quantity

Remark

1

TRD1 G2A

1

Up to 8 cameras at most

2

T4JC-JC-ZZZZ-0500L(Female to Female 0.5m)

2

Standard configuration

3

Trigger Cable

1

Standard configuration

4

Power Conversion Cable

1

Standard configuration

5

Power adapter1Standard configuration

6

Multi-functional conversion socket1

optional configuration




       Product specifications and instructions


        Click to download undefinedTRD1 G2A‍ Developer Kit‍ Datasheet‍‍‍‍‍

‍


undefined       Other technical documents

        If you need more information, please contact the sales of SENSING or contact Support@sensing-world.com with QR code on camera attahced to obtain.
